| Nazwa marki: | XIWUER |
| Numer modelu: | CT8-1-30kV-2700pF |
| MOQ: | 5 |
| Cena: | negocjowalne |
| Warunki płatności: | L/C, T/T |
| Możliwość zaopatrzenia: | 3 000 000 sztuk rocznie |
Wymagania
L=25±2mm H=21±2mm
D=80±2 mm d=12±0,2 mm nici M5
Parametry techniczne
| Typowe modele parametry elektryczne: | |||||||||
| Kwadrat | Numer modelu | Strata dielektryczna | Wytrzymaj napięcie | Odporność na izolację | Wymiar ((mm) | ||||
| D | H | L | D | M | |||||
| 1 | 20kV-2000pF | ≤ 0.004 | 1.5ur? 60s | ≥ 1,0 x 106MΩ | 45 | 19 | 23 | 12 | 5 |
| 2 | 20kV-10000pF | 65 | 15 | 19 | 12 | 5 | |||
| 3 | 20kV-18000pF | 80 | 17 | 25 | 12 | 5 | |||
| 4 | 30kV-1000pF | 45 | 24 | 32 | 12 | 4 | |||
| 5 | 30kV-2700pF | 60 | 20 | 28 | 12 | 4 | |||
| 6 | 30kV-12000pF | 74 | 18 | 26 | 12 | 5 | |||
| 7 | 40 kV-150 pF | 20 | 33 | 41 | 8 | 4 | |||
| 8 | 40kV-500pF | 28 | 33 | 41 | 8 | 4 | |||
| 9 | 40kV-7500pF | 80 | 24 | 29 | 12 | 6 | |||
| 10 | 40 kV-10000 pF | 80 | 22 | 26 | 16 | 5 | |||
| 11 | 50kV-1000pF | 50 | 30 | 34 | 12 | 4 | |||
| 12 | 50kV-1000pF | 32 | 27 | 31 | 16 | 5 | |||
| 13 | 50kV-5600pF | 80 | 31 | 35 | 16 | 5 | |||
| 14 | 60 kV-1500 pF | 50 | 31 | 34 | 12 | 5 | |||
| 15 | 60kV-3000pF | 65 | 32 | 35 | 16 | 5 | |||
| 16 | 100kV-500pF | 50 | 54 | 58 | 12 | 5 | |||
| 17 | 100kV-2000pF | 51 | 32 | 35 | 16 | 5 | |||
| 18 | 100 kV - 1500 pF ((Typ izolacji) | 68 | 36 | 40 | 16 | 5 | |||
| 19 | 150 kV-820 pF | 65 | 95 | 100 | 12 | 5 | |||
| 20 | 200 kV-600 pF | 50 | 90 | 94 | 16 | 5 | |||
